NPBoosted

 Four Performance 118Mj / 41kV Inductive “Dumb” Type Ignition Coil Packs 4 Cylinder Application for Haltech Fueltech Microtech AEM Fast
Fitment Guide:Custom Hi Performance Application – 4 CylinderInline 4 / Flat 4 EnginesTurbo / Supercharged / Nitrous / High Compression
Popular Custom Coil Upgrade Choice on N54 Twin Turbo / N55 N20 Single Turbo BMW Engines4 Cylinder 4B11 4G63 EJ20 B16 B18 K20 K24 F20 SR20DET 13BT 3S-GTE
Fast & Free Shipping: USA & CanadaWorldwide Shipping: $49.95
Package Contents:(4) Hi Energy 118 mJ – 41kV Output Inductive Ignition Coil Packs(4) Wire Harness Pigtails w/ Connector Clip Plugs( 3 PIN ) Connector Plug
Specs:Primary Resistance: 0.5 Ω +/- 10%Primary Inductance: 4.8 mH +/- 15%Secondary Resistance: 8.5 kΩ +/- 20%Secondary Inductance: 22.5 H +/- 20%Output (50pF load): 41 kV +/- 10%Output Energy: 118 mJ +/- 7%Peak Secondary Current: 100 mA +/- 7%Arc Duration: 3.2 mS +/- 10%Turns Ratio 71:1Maximum Battery Voltage: 17 VoltsBase Dwell: 3.0 mSMax Continuous Dwell: 9 mS but don’t exceed 40% duty cycleMax Intermittent Dwell: 80% duty cycle, 5 seconds maximumHigh Tension Wire Terminal: HEI “spark plug top” Style

Cross Reference Part Numbers:

NP-0227IC-6, 30-2852, 302852, 601-0021, 601-0108, 8232
