Description

NPBoosted Fuel Injectors

8 Pcs Hi Impedance 60lb EV1 Performance Fuel Injectors for Ford Chevy Pontiac LT1 LS1 LS6 630cc PLUSS++ EV1 Injector Harness / Pigtaits & Connector Clips 8 Pack
Fitment Guide:

These are Aftermarket High Impedance Injectors ( Approx 12 OHMS )

Saturated injectors will fit all of the following models:

1994-1995 BMW 530i1994-2003 BMW 540i2004-2005 BMW 545i2004-2005 BMW 645Ci2006-2007 BMW 650i1993-2001 BMW 740i, iL2002-2005 BMW 745i, Li2006-2007 BMW 750i, Li1994-1997 BMW 840Ci2007-2008 BMW Alpina B72000-2003 BMW M52000-2007 BMW X52000-2003 BMW Z81985-2002 Chevrolet Camaro1985-2004 Chevrolet Corvette1994-1996 Chevrolet Impala1986-1995 Ford Mustang GT, LX and Cobra 5.0L1996-2004 Ford Mustang GT1999-2004 Ford Lightning1996-2004 Lotus Esprit1985-2002 Pontiac Firebird2004-2006 Pontiac GTO1985-2002 Pontiac TransAm

The following models must change injector plugs, we include EV1 Injector Plugs

2010-2013 Chevrolet Camaro 2005-2013 Chevrolet Corvette 1999/2001 Ford Mustang Cobra 2003-2004 Ford Mustang Mach I2003-2004 Ford Mustang Cobra 2005-2013 Ford Mustang V8

The following models require spacers and longer fuel rail bolts and must change injector plugs, we include EV1 Injector Plugs

2005-2013 Chrysler 300C HEMI 2008-2012 Dodge Challenger HEMI 2006-2012 Dodge Charger HEMI 2005-2008 Dodge Magnum HEMI 2006-2013 Jeep Grand Cherokee SRT8Any BMW 8 cylinder model with Bosch EV1 style injectorsAny Ford V8 Engine with Bosch EV1 style injectorsFast & Free Shipping: USA & CanadaWorldwide Shipping: $49.95 THESE HIGH PERFORMANCE INJECTORS WILL REQUIRE ECU TUNING
INJECTOR CLIPS MAY BE REQUIRED FOR SOME MODELS

Specs:

· Quantity: 8 Fuel Injectors· Condition: 100% BRAND NEW· Design: Bosch GEN III EV1 Style Fuel Injector· O-Rings Included: Yes, preinstalled· Injector Design: Metal & composite plastic· Orifice Type: 1 hole· Connector Type: Bosch EV1· Filter Design: Basket filter design at inlet· Fuel Delivery: Single Nozzle Cone Shape· Spray Pattern: 15 Degree Spray Cone

Technical Data

· Coil Resistance: 12 Ohms / High Impedance· Static Flow Rate at 43.5PSI ( 300kPa ) w/Gas: 60 lb/hr = 630 cc/min· Static Flow Rate at 45PSI ( 310kPa ) w/Gas: 63 lb/hr = 650 cc/min· Gain: 0.12ms/MG· Offset: 0.055ms· Turn on time at 14VDC: 1.14ms· Turn off time: 0.85ms @ 600KPa· Voltage: 8-15 Volts, nominal 13.5 Volts· Amperage: 1.0 Amps· Pressure: Min 30PSIG/ Max 100PSIG· Variance:2%

Injector Dimensions:

Overall Length: 2 7/8 inches, 74 mmO-ring to O-ring Length: 2 1/2 inches, 63 mmDiameter: 16 mmOrings: Top and bottom, 14.5 mm

Cross Reference Part Numbers:

FI114961, 107961, NP-FI4961
