Regulator Rectifier 6 Wires w/ Fuse Plug FITS Mercury Mariner & More 2 Stroke 40HP 75HP 125HP to 200 HP 2.5L V6 1994+ & later model Outboards Motor Watercrafts

6 WIRE AFTERMARKET VOLTAGE REGULATOR / RECTIFIER FITS

MARINER / MERCURY OUTBOARD MARINE APPLICATIONS

Regulator Rectifier for Mercury Outboards late model – 6 Wire

Replaces Mercury part numbers 883072T, 854515T1, 854515, 856748, 815279T, 815279-3, 815279-5, 830179T, 830179-2.

This new rectifier is a “6-Wire” w/ Fuse Plug kit, it’s designed for several applications for both Mercury Outboard from 30-200HP and Force 40-150 HP.

Fast & Free Shipping: USA & Canada

Worldwide Shipping: $49.95

The Terminals are designed as the following:

Grey – Tach

Yellow – AC

Red (Female) – Sense

Red (Male) – B+

Black – B-

Yellow – AC

 Features:

•  T-Clad Hybrid construction
•  Series type Rectifier/Regulator
•  Marine Engine Applications
•  TACH output

Cross Reference Part Numbers:

MERCURY MARINE: 815279-3, 815279-5, 815279T, 830179-2, 830179T, 854515, 856748, 883072, 883072T, 8M0006034, 856748, 883072, 883072T, 1784M, 18-5743, 8M0045112
